Combination Switch

NOTE: Combination switch includes switches for headlights, turn signals and windshield wipers. For testing, see appropriate component procedure.
Fig 1: Identifying Combination Switch Connector Terminals
G93J84664Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
