Removal & Installation: Starter: Removal

1. Disconnect negative battery at battery. See Fig 1.
2. Disconnect magnetic switch lead wire and battery cable from starting motor terminals.
3. Remove 2 starting motor mount bolts (2).
4. Remove starting motor (1).

Fig 1: Disconnecting Negative Cable At Battery

Courtesy of SUZUKI OF AMERICA CORP.
