Timing Chain
WARNING: This page is about a different variant/trim than selected.
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 7.8 (0.8, 5.8)
T3: Refer to CAM SPROCKET .
T4: 16 (1.6, 11.8)
T5: 69 (7.0, 50.9)
T6: Refer to OIL PUMP .
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 7.8 (0.8, 5.8)
T3: Refer to CAM SPROCKET .
T4: 16 (1.6, 11.8)
T5: 69 (7.0, 50.9)
T6: Refer to OIL PUMP .
