ABS Control Module and Hydraulic Control Unit (ABS CM & H/U): Inspection: Notes

  1. Check the connected and fixed condition of connector.
  2. Check specifications of the mark with ABS CM & H/U.
    MARK MODEL SPECIFICATIONS

    Mark Model
    L4 AT
    L5 MT
    Fig 1: Checking Clearance
    G03808453Courtesy of SUBARU OF AMERICA, INC.
