Special Tools

WARNING: This page is about a different car, the 2007 Cadillac STS. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J-8092 Driver Handle
Courtesy of GENERAL MOTORS CORP.	J-8614-01 Flange and Pulley Holding Tool
Courtesy of GENERAL MOTORS CORP.	J-21474-20 Bushing Installer
Courtesy of GENERAL MOTORS CORP.	J-22912-01 Rear Pinion and Axle Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J-25070 Heat Gun - 500-750F
Courtesy of GENERAL MOTORS CORP.	J-44394 Seal Protector
Courtesy of GENERAL MOTORS CORP.	J-45012 Holding Fixture
Courtesy of GENERAL MOTORS CORP.	J-45017 Seal Installer
Courtesy of GENERAL MOTORS CORP.	J-45019 Flange and Pinion Cage Remover
Courtesy of GENERAL MOTORS CORP.	J-45124 Removal Bridge
Courtesy of GENERAL MOTORS CORP.	J-46262 Pinion Sealer
Courtesy of GENERAL MOTORS CORP.	J-46265 Stub Shaft Seal Installer
