Torque Specifications
WARNING: This page is about a different car, the 1998 Pontiac Grand Am, 1998 Oldsmobile Achieva, and 1998 Buick Skylark. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Column Bracket-To-Support Bolts | 20 (27) | |
| Lower & Upper Pinch Bolts | 30 (41) | |
| Steering Wheel Nut | 30 (41) | |
| INCH Lbs. (N.m) | ||
| Air Bag Module Screws | 89 (10) | |
| Ignition Switch Screws | ||
| With Tilt Column | 15 (1.7) | |
| Without Tilt Column | 12 (1.4) | |
| Interlock Solenoid Screws (Column Shift) | 13 (1.5) | |
| Linear Shift Assembly Screws With Tilt Column | 89 (10) | |
| Lock Bolt Support Bracket Screws | 31 (3.5) | |
| Radio Control Screws | 9 (1) | |
| Steering Column Cover Screws | 80 (9) | |
| Steering Column Electric Park Lock Screw With Floor Shift | 12 (1.4) | |
| Steering Column Housing Screws | 53 (6) | |
| Steering Column Support Screws | ||
| Non-Tilt Column | 71 (8) | |
| Tilt Column | 80 (9) | |
