Component Description

Air bag warning lamp turns ON indicating a system malfunction when a malfunction is detected for electric system of SRS air bag system and pre-tensioner seat belt system.

Courtesy of NISSAN NORTH AMERICA, INC.
For operation check purposes, air bag warning lamp turns ON for 7 seconds after power switch is placed ON. During this period of time, air bag diagnosis sensor unit performs system diagnosis.
NOTE: SRS air bag and pre-tensioner seat belt do not operate for approximately 7 seconds (air bag warning lamp is turning ON) after power switch is placed ON.
