P and N Positions
- P position
Similar to the N position, the clutches do not operate. The parking pawl engages with the parking gear to mechanically hold the output shaft so that the powertrain is locked.
- N position
Power from the input shaft is not transmitted to the output shaft because the clutches do not operate.
