Disassembly And Assembly: Notes

Fig 1: Disassembling/Assembling Control Housing Components Location With Torque Specification

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tools:

• MB992000: Crankshaft Adapter
• MD998245: Installer Lock Pin
