Special Tools

WARNING: This page is about a different car, the 2023 Mitsubishi Eclipse Cross. However, it is still accessible from the selected car via links, so may be relevant.
  Tool number and name Supersession Application
G16251141Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
  1. MB992744
  2. MB992745
  3. MB992747
  4. MB992748
M.U.T.-IIISE
  1. Vehicle communication interface-Lite (V.C.I.-Lite)
  2. V.C.I.-Lite main harness A (for vehicles with CAN communication)
  3. V.C.I.-Lite USB cable short
  4. V.C.I.-Lite USB cable long
 - DTC, service data and actuator test check.
G09625236Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
 MB991223
  1. MB991219
  2. MB991220
  3. MB991221
  4. MB991222

Harness set
  1. Test harness
  2. LED harness
  3. LED harness adaptor
  4. Probe
 General service tools Continuity check and voltage measurement at harness wire or connector for loose, corroded or damaged terminals, or terminals pushed back in the connector.
  1. Connector pin contact pressure inspection
  2. Power circuit inspection
  3. Power circuit inspection
  4. Commercial tester connection
G08294095Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
 MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting
- MB993010 Calibration marker Camera calibration
NOTE: At least two calibration markers are required for calibration.
