Differential Carrier Assembly: Assembly: Notes
WARNING: This page is about a different variant/trim than selected.
Required Special Tools:
- MB990810: Side Bearing Puller
- MB990829: Pinion & Side Bearing Installer
- MB990930: Installer Adapter
- MB990934: Installer Adapter
- MB990938: Installer Bar
- MB991115: Oil Seal Installer
- MB991180: Bush Remover & Installer Base
- MB992111: Side Bearing Holder
- MB992112: Lock Nut Wrench
- MB992113: Drive Pinion Holder
- MB992115: Dummy Pinion Gauge body
- MB992116: Dummy Pinion Gauge Head
- MB992117: Cylinder Gauge
- MB992128: Hex Socket Head Bolt
- MD998816: Installer Adapter
