Removal and Installation
- Turn the steering wheel to the straight ahead position and turn the ignition switch to the OFF position.
- Remove and discard the upper and lower steering column shaft pinch bolts and remove the coupler.
- To install, reverse the removal procedure.
CAUTION:
Do not allow the steering wheel to rotate while the steering column intermediate shaft is disconnected or damage to the clockspring can result. If there is evidence that the intermediate shaft has rotated, the clockspring must be removed and recentered. For additional information, refer to SUPPLEMENTAL RESTRAINT SYSTEM
.
NOTE:
Discard the upper and lower intermediate shaft-to-steering column shaft pinch bolts upon removal. Do not reuse; install new bolts.
CAUTION:
Do not allow the steering wheel to rotate while the steering column intermediate shaft is disconnected or damage to the clockspring can result. If there is evidence that the intermediate shaft has rotated, the clockspring must be removed and recentered. For additional information, refer to SUPPLEMENTAL RESTRAINT SYSTEM
.
