Passenger Air Bag Module: Notes

Fig 1: Exploded View Of Passenger Air Bag Module With Torque Specification
G06284651Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W706473 Passenger air bag module screw (12 required)
2 044A74 Passenger air bag module
3 - Panel duct assembly screws (6 required)
4 19B680 Panel duct assembly
