FRONT SPEED SENSOR (for 2WD): Components

Fig 1: Brake Control Front Speed Sensor (For 2WD) Replacement Components With Torque Specifications

G04025232

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
