Window Regulator (Rear): Removal

  1. Remove door trim panel. See DOOR TRIM (REAR)
  2. Remove the window regulator. Using a clip remover, disconnect the connector clip. See Fig 1.
    Fig 1: Removing Rear Window Regulator
    G00148012Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  3. Remove the regulator with 4 bolts. See Fig 1.
