Driver Side

WARNING: This page is about a different car, the 2020 Kia Niro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative (-) battery terminal.
  2. Remove the main crash pad assembly.

    (Refer to Body - "MAIN CRASH PAD ASSEMBLY ".)

  3. Remove the driver side shower duct (A) after loosening the screw.
    G13351687Courtesy of KIA MOTORS AMERICA, INC.
  4. Install in the reverse order of removal.
