Overhead Console Lamp: Replacement

  1. Disconnect the negative (-) battery terminal.
  2. Replace the bulb after removing the lens with a flat-tip screwdriver.
    Fig 1: Identifying Overhead Console Lamp Bulb
    G04885167Courtesy of KIA MOTORS AMERICA, INC.
  3. Remove the bulb and replace it with a new one
    NOTE: Take care that holding clip (A) is not to be damaged
