Inspection Procedure 2

STARTING IMPOSSIBLE PROBABLE CAUSE CHART

Starting impossible	Probable cause
Starting is not possible when the selector lever is in P or N range. In such cases, the cause is probably a defective engine system, torque converter or oil pump.	Malfunction of the engine system Malfunction of the torque converter Malfunction of the oil pump

Fig 1: Identifying Starting Possible Selector Lever

Courtesy of KIA MOTORS AMERICA, INC.
