Media Monitor/DVD Shield System Connector End View

WARNING: This page is about a different car, the 2005 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.

MEDIA SYSTEM-MONITOR/DVD SHIELD - 1 WAY

Courtesy of DAIMLERCHRYSLER CORP.
CAV	CIRCUIT	FUNCTION
1	X207 20GY/LB	SHIELD
