Rear Power Distribution Fuse Box
Rear power distribution fuse box is located to the right of the spare tire. See Figure . The rear power distribution fuse box contains Printed Circuit Board (PCB) relays that are not serviced separately. If a PCB relay fails, the rear power distribution fuse box assembly must be replaced. For rear power distribution fuse box relay and fuse configuration, see Fig 1 .
