Removal and Installation: Removal

  1. Disconnect the battery cable from the negative terminal.
  2. Remove engine front undercover, using power tools.
  3. Remove radiator cooling fan assembly. Refer to "EXPLODED VIEW ".
  4. Remove drive belt. Refer to "REMOVAL AND INSTALLATION ".
  5. Disconnect alternator connector (1).
  6. Remove "B" terminal nut (2).
  7. Remove the harness bracket bolts (A).
    Fig 1: Identifying Alternator Components
    G04878571Courtesy of NISSAN MOTOR CO., U.S.A.
  8. Remove oil pressure switch harness clip (C) from alternator stay (1).
  9. Disconnect oil pressure switch connector (D) and oil temperature sensor connector (E).
  10. Remove alternator mounting bolt (B) and alternator stay mounting bolt (F) using power tools, then remove alternator stay.
  11. Remove alternator mounting bolt (A), using power tools.
    Fig 2: Identifying Oil Pressure Switch And Oil Temperature Bolt Connector
    G05226769Courtesy of NISSAN MOTOR CO., U.S.A.
  12. Remove alternator assembly downward from the vehicle.
