Notes
Removal and Installation: Notes
Fig 1: Actuator And Electric Unit (Assembly) Replacement Components With Torque Specifications
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
