Air Fuel Ratio (A/F) Sensor

The A/F sensor operates over a wide air/fuel range. The A/F sensor is installed the exhaust manifold, and sends signals to the ECM/PCM which varies the duration of fuel injection accordingly.

Fig 1: Sectional View Of Air Fuel Ratio (A/F) Sensor

Courtesy of AMERICAN HONDA MOTOR CO., INC.
