2000-2003 Models

NOTE: Use new gaskets and self-locking nuts when reassembling.
Fig 1: Identifying Exhaust Manifold Replacement Components - 2000-2003 Models With Torque Specifications
G03692500Courtesy of AMERICAN HONDA MOTOR CO., INC.
