Charging System - 2.5L: Alternator: Specifications: Specification

13.5 V 150 A

Item	Specification
Form	AC power generation
Rated Voltage	13.5 V 150 A
Motor RPM	1, 000 - 18, 000 RPM
Regulator voltage	14.2 - 14.8
Connector pin count	1
Pulley Type	OAP

Courtesy of HYUNDAI MOTOR AMERICA
