WASTEGATE Control Valve Connector End View (C1674)

Fig 1: Identifying Wastegate Control Valve Connector (C1674)

Courtesy of FORD MOTOR CO.

Pin	Circuit	Gauge	Circuit Function	Qualifier
1	CE149 (VT-OG)	20	CTRL MOD. - POWERTRAIN # ENGINE COOLANT RESERVOIR VALVE
2	CBB34 (VT-BN)	20	FUSE - 34 OR CIRCUIT BREAKER
