Locker Switch 2 Connector End View

LOCKER SWITCH NO. 2

GCVA580199Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 16BR/BK LOCKER SWITCH NO. 2 OUTPUT
2 16BK/RD FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
