Standard Procedure

Periodic lubrication of suspension system is required. The following lubrication points on suspension system must be lubricated periodically. See Fig 1 .

Front Suspension:

• Upper Control Arm Ball Joint
• Lower Control Arm Ball Joint
• Outer Tie Rods

Lubricate each point until a slight swelling is noticed in seal boot. Do not overfill seal boots.

Fig 1: Lubrication Points

Courtesy of DAIMLERCHRYSLER CORPORATION
