Installation Procedure

    Fig 1: View Of Inside Door Handle Components
    GM1256824Courtesy of GENERAL MOTORS CORP.
  1. Connect the inside door handle and the lock rods.
  2. Insert the inside door handle into the slots in the door.
  3. Slide the door handle forward.
  4. Install the door seal trim. Refer to Trim Panel Replacement - Front Door in Interior Trim.
