Manual Transmission - M49: Specifications
Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Backup Lamp Switch | 38 N.m | 28 lb ft |
| Clutch Actuator Cylinder Bolts | 8 N.m | 71 lb in |
| Flywheel Housing Bolts/Nuts | 95 N.m | 70 lb ft |
| Flywheel Housing Cover Bolts | 9 N.m | 80 lb in |
| Shift Control Closeout Boot Bolts | 2 N.m | 18 lb in |
| Shift Control Knob | 3 N.m | 27 lb in |
| Speed Sensor Bolt | 10 N.m | 89 lb in |
| Transmission Bolts | 75 N.m | 55 lb ft |
| Transmission Brace Bolts, Left Side to Engine | 28 N.m | 21 lb ft |
| Transmission Brace Bolts, Left Side to Transmission | 50 N.m | 37 lb ft |
| Transmission Brace Bolts, Right Side | 50 N.m | 37 lb ft |
| Transmission Case Drain/Fill Plug | 27 N.m | 20 lb ft |
| Transmission Control Lever Bolts | 17 N.m | 13 lb ft |
| Transmission Mount Bolt | 48 N.m | 35 lb ft |
| Transmission Mount Nut | 57 N.m | 42 lb ft |
| Transmission Support Bolts | 57 N.m | 42 lb ft |
| Wiring Harness Clip Bolt | 11 N.m | 97 lb in |
