Test B: Scan Tool Will Not Communicate With Class 2 Components

Refer to flowchart. See Fig 1 .

Fig 1: Scan Tool Will Not Communicate With Class 2 Components Diagnostic Flowchart

Courtesy of GENERAL MOTORS CORP.
