Telephone BASEPLATE -R126-

WARNING: This page is about a different variant/trim than selected.

-- Turn off all electrical consumers.

-- Remove the key.

Removing

-- Remove the telephone handset -R37-.

-- Remove SIM card mount.

-- Remove the storage compartment from the center console. Refer to Removal and Installation

-- Disconnect the connector -1-.

Fig 1: Disconnecting Connector

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -2- on the back side.

-- Push the Telephone baseplate upward out of storage compartment.

Installing

-- Install in reverse order of removal.
