Telephone BASEPLATE -R126- For Cell Phone

-- Turn off all electrical consumers.

-- Remove the key.

Removing

-- Remove the storage compartment from the center console. Refer to Removal and Installation .

-- Disconnect the connector -1-.

Fig 1: Disconnecting Connector

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -2- on the back side.

-- Push the Telephone baseplate upward out of storage compartment.

Installing

-- Install in reverse order of removal.
