Disassembly & Reassembly

Manufacturer does not supply overhaul procedures. Use exploded views, in aid to overhaul steering gear. See Fig 1 or Fig 2 .

Fig 1: Exploded View Of Steering Gear Without Dampener (1.8L Turbo: AEB, ATM & AWM)

Courtesy of AUDI OF AMERICA, INC.

Fig 2: Exploded View Of Steering Gear With Dampener (2.8L V6: AFC, AHA & ATQ)

Courtesy of AUDI OF AMERICA, INC.
