3rd Clutch Pressure Switch Replacement

  1. Remove the switch cover (A).
    Fig 1: Removing Switch Cover
    G01160372Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Disconnect the connector from the 3rd clutch pressure switch (B).
  3. Replace the 3rd clutch pressure switch, then install a new one with a new sealing washer (C). Tighten the switch on the metal part, not the plastic part.
  4. Reconnect the connector, making sure there is no water, oil, dust, or other foreign particles inside it.
  5. Install the switch cover.
